供应全球优质的滑动承载延伸系统
5117.SHJY.2027 10-20kg
| 安装间隙: | 9.9 |
| 高度: | 27.1 |
| 闭合长度: | 250-500mm |
| 延展长度: | 167-444mm |
| 最大载重: | 10-20kg/pair |
| 滑轨节数: | 2 |
| 延展程度: | Partial |
| 材质: | Zinc plated steel |
| 抗震动性: | 3 |
| 产品编号 | 闭合长度（mm） | 延展长度（mm） | 最大载重（kg） |
|---|---|---|---|
| 5117.SHJY2701T.006 | 150mm | 99.9mm | 18kg |
| 5117.SHJY2701T.008 | 200mm | 133.2mm | 18kg |
| 5117.SHJY2701T.010 | 250mm | 166.5mm | 18kg |
| 5117.SHJY2701T.012 | 300mm | 199.8mm | 18kg |
| 5117.SHJY2701T.014 | 350mm | 233.1mm | 18kg |
| 5117.SHJY2701T.016 | 400mm | 266.4mm | 18kg |
| 5117.SHJY2701T.018 | 450mm | 299.9mm | 16kg |
| 5117.SHJY2701T.020 | 500mm | 333.3mm | 14kg |
| 5117.SHJY2701T.022 | 550mm | 366.6mm | 12kg |
| 5117.SHJY2701T.024 | 600mm | 399.6mm | 10kg |
型录＆主要产品资讯
5117.SHJY2701T.006 length 150mm- 3D STEP FILE -
5117.SHJY2701T.006
5117.SHJY2701T.008 length 200mm- 3D STEP FILE -
5117.SHJY2701T.008
5117.SHJY2701T.010 length 250mm- 3D STEP FILE -
5117.SHJY2701T.010
5117.SHJY2701T.012 length 300mm- 3D STEP FILE -
5117.SHJY2701T.012
5117.SHJY2701T.014 length 350mm- 3D STEP FILE -
5117.SHJY2701T.014
5117.SHJY2701T.016 length 400mm- 3D STEP FILE -
5117.SHJY2701T.016
5117.SHJY2701T.018 length 450mm- 3D STEP FILE -
5117.SHJY2701T.018
5117.SHJY2701T.020 length 500mm- 3D STEP FILE -
5117.SHJY2701T.020
5117.SHJY2701T.022 length 550mm- 3D STEP FILE -
5117.SHJY2701T.022
5117.SHJY2701T.024 length 600mm- 3D STEP FILE -
5117.SHJY2701T.024
4013.3213 Enquiry
